Beginner-Friendly Vape Oil Piercing Tool and Cotton Starter Kit

Customization:	Available
After-sales Service:	Remote Support Instructions by Email
Warranty:	Six Months

Basic Information

Model NO.

SF25 6+3

Type

General Punching Machine

Punch Shape

Semi-Open Punch

Slider Movement

Triple Action

Drive Mechanism

Crank Press

Controlling Mode

CNC

Automatic Grade

Automatic

Power Source

Joint Drive

Precision

High Precision

Certification

ISO 9001

Main Motor

7.5kw

Tonnage

25ton

Product Description

01

Intuitive HMI: Digital control, plug-and-play automation; stackable, flexible, and high-efficiency.

02

Robust Construction: Cast frame with three-post guidance; front-to-back pass-through, steady accuracy, variable speed, and overload protection.

03

Advanced Feeding: Simultaneous left-right & front-back feeds eliminate multi-layer web clash; features auto wind, blank, and stop on fault.

The dedicated Vape Oil Guide Cotton Blanking Machine is a precision-engineered solution tailored exclusively for the e-cigarette manufacturing industry. It specializes in automated blanking and cutting of oil guide cotton components. Equipped with advanced servo-driven feeding and high-precision die-cutting mechanisms, the machine ensures ultra-flat cut edges and consistent dimensional accuracy (tolerance within ±0.01mm). It adapts seamlessly to various oil guide cotton specifications, including organic and composite materials.

Product Parameters

Specification	Unit	25TON Data
Impulse generating position	mm	1.2
Stroke length	mm	60
Maximum closing working height	mm	175-205
Number of strokes	s.p.m	60-150
Adjustment amount of sliding block	mm	30
Upper table size	LRXFB	400x300
Main motor	KW	7.5
Number of cigarette cotton reels	-	4+2 / 5+2 / 6+2

Detailed CAD drawings and dimensional diagrams are available upon inquiry. Our engineering team can provide tailored designs to meet specific project requirements.
